Pro-code: NR0024

Availability: In stock

Robust construction gives accurate results, ±4%, even in arduous working conditions.
The break angle improves accuracy by reducing the possibility of over torquing.
Dual scaled, N·m and lbf·ft.
All models are also available as Production 'P' types with no setting scale. These must be set against a torque testing device such as Norbar’s Professional Torque Tester.
Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Square Size: 3/4
Torque Radius: 683.4 mm
Ratchet Teeth: 36
Ratchet Type: push-through
Scale Increments (N·m): 10
Scale Increments (lbf·ft): 10
- Tool Weight (kg): 5.15
- Packed Weight* (kg): 7.05
- Packed Width* (W) (mm): 970.00
- Packed Height* (H) (mm): 95.00
- Packed Depth* (D) (mm): 233.00
* Estimated
